3D Slicer Orthodontics: Align Digitally

Orthodontics in 3D Slicer feels experimental but surprisingly functional. I first used it for simple tooth alignment, and it worked better than expected. There’s no subscription wall — just a bit of patience and YouTube tutorials.

Modules for Alignment

You can import STL models from intraoral scanners and overlay them on CBCT. Alignment is manual at first, then fine-tuned with fiducials.

What actually helps:

• “Markups to Model” tool for defining tooth surfaces

• Elastic registration — pretty accurate for arch forms

• Transform Hierarchy window — weird but essential

• Cephalometric analysis plugin (download separately)

Observation

It seems built for researchers rather than daily clinical use, yet results are solid after practice.

How to Align Teeth in Slicer

Workflow I follow:

1. Load CBCT and STL of dental arch.

2. Use Landmark Registration to match surfaces.

3. Apply Transform and check fit in 3D view.

4. Segment teeth individually if needed.

5. Simulate movement with Transform Editor.

Tips

Save each step — Slicer crashes sometimes when handling multiple STLs.

Feature Comparison

Pros and Cons

Advantages:

• Zero license cost

• Integrates STL and CBCT nicely

• Open for research extensions

Disadvantages:

• UI non-intuitive

• Manual steps tiring

• No official orthodontic support

Conclusion

For students or clinicians testing digital alignment, 3D Slicer is worth a look. It’s rough around the edges but surprisingly capable once you get the hang of it.
